Product Overview
IP44 Wall Socket & Mounted Plugs designed for industrial applications. Wall-mounted installation with safe, reliable, high strength and heat resistance, good electrical contact, fireproof and waterproof properties. Suitable for voltages below AC415V and rated current of 16A or 32A. Ambient temperature: -20°C~40°C. Can work in environments with dust and moisture, but not with explosive gas or corrosion.
Socket Models: 3033202B, 3033201B, 3043201B, 3053201B
Mounted Plug Models: 3133202B, 3133201B, 3143201B, 3153201B
Socket Dimensions (mm)
| Ampere | Pole | A | B | C | D | E |
|---|---|---|---|---|---|---|
| 32A | 3 | 33.5 | 58.5 | 142.5 | 79 | 71 |
| 32A | 4 | 33.5 | 58.5 | 142.5 | 79 | 71 |
| 32A | 5 | 33.5 | 58.5 | 142.5 | 79 | 71 |
| 16A | 3 | 33.5 | 58.5 | 142.5 | 79 | 71 |
| 16A | 4 | 33.5 | 58.5 | 142.5 | 79 | 71 |
| 16A | 5 | 33.5 | 58.5 | 142.5 | 79 | 71 |
Mounted Plug Dimensions (mm)
| Ampere | Pole | A | B | C | D | E |
|---|---|---|---|---|---|---|
| 32A | 3 | 33.5 | 58.5 | 136 | 71 | 71 |
| 32A | 4 | 33.5 | 58.5 | 136 | 71 | 71 |
| 32A | 5 | 33.5 | 58.5 | 136 | 71 | 71 |
| 16A | 3 | 33.5 | 58.5 | 136 | 71 | 71 |
| 16A | 4 | 33.5 | 58.5 | 136 | 71 | 71 |
| 16A | 5 | 33.5 | 58.5 | 136 | 71 | 71 |
Certifications
- CE Certified
- CB Scheme
- RoHS Compliant
